Product Details:
|
Length Overall (ladder Raised): | 25m | Maximum Standard Dredging Depth: | 30m |
---|---|---|---|
Engine: | 1342kw | Discharge Port: | 25inch |
Length: | Customizable Size | Purpose: | River Dredging |
High Light: | Automatic Multi Span Greenhouses,PE Blackout Multi Span Greenhouses,PE Blackout Vegetable Tunnel Farming |
Model | Dimension (L*w*h) | Design draught | Dredging depth | Water flowing | Total weight |
HD-CSD150 | 25*4.7*1.26m | 0.8m | 12m | 450m3/h | 29t |
HD-CSD200 | 26*5.3*1.5m | 1.0m | 12m | 800m3/h | 38t |
HD-CSD250 | 32.5*5.3*1.5m | 1.0m | 15m | 1500m3/h | 55t |
HD-CSD300 | 33*6.6*1.8m | 1.2m | 15m | 1800m3/h | 82t |
HD-CSD350 | 35*6.8*2.0m | 1.4m | 15m | 2500m3/h | 110t |
HD-CSD450 | 37*7.9*2.2m | 1.6m | 15m | 3500m3/h | 155t |
HD-CSD500 | 39*9.0*2.5m | 1.9m | 15m | 5000m3/h | 210t |
HD-CSD600 | 42*10*2.8m | 2.2m | 15m | 7000m3/h | 300t |
Length overall (ladder raised) | 26m |
Breadth | 5.3m |
Depth | 1.5m |
Design draught | 1.0m |
Maximum standard dredging depth | 12m |
Diameter of discharge pipe | 250mm |
Max. mixture capacity | 800m3/h |
Dredge pump power | 220kw |
Cutter power | 40kw |
Total weight | 38t |
