Product Details:
|
| Weight: | 20 Ton | Application: | Automatic Equipment |
|---|---|---|---|
| Product Name: | Shantui 20 Ton Hydraulic Crawler Excavator With Cummins Engine | Color: | Yellow Or As Required |
| Size: | Customized | Certification: | ISO9001 |
| High Light: | 20 Ton Hydraulic Crawler Excavator,Cummins Engine Hydraulic Crawler Excavator,ISO9000 Hydraulic Excavator |
||
Amphibious excavator with under carriage for work in river
SE215 Excavator
TECHNICAL PARAMETERS
| Engine Model | Cummins QSB7 |
| Gross Power | 124 kW/2050 rpm |
| Operating Weight | 21200 kg |
| DIMENSIONS (mm) | |||
| A | Overall length | 9625 | |
| B | Ground contact length (Transportation) | 4915 | |
| C | Overall height(to top of boom) | 3075 | |
| D | Overall width | 2800 | |
| E | Overall height(to top of cab) | 3090 | |
| F | Counter weight ground clearance | 1075 | |
| G | Ground clearance | 470 | |
| H | Tail swing radius | 2925 | |
| I | Tread | 3360 | |
| J | Track length | 4140 | |
| K | Track gauge | 2200 | |
| L | Track width | 2800 | |
| M | Shoe width | 600 | |
| O | Bonnet height | 2395 | |
| P | Revolving frame width | 2725 | |
| Q | Distance from swivel center to tail | 2920 | |
SCOPE OF WORK (mm) (Boom: 5700 mm Arm: 2925 mm) A Max. digging height 10080
C Max. digging depth 6490
D Max. vertical digging depth 5950
E Max. Depth cut for 2500mm Level Bottom 6295
F Max. digging distance 9860
G Max. digging radius at ground level 9675
H Min. swing radius of work equipment 2970
